Fire Detection and Notification System Design
We design complete fire detection and alarm systems that comply with local codes, NFPA, UL, and industry best practices, delivering fully coordinated, approval-ready design packages.
Our expertise also includes the design and placement of beam-type smoke detectors for large or high-ceiling spaces where there is a risk of smoke layer stratification. Using advanced analysis, we predict the height of smoke stratification to ensure optimal detector positioning and early warning reliability.
In addition, we perform 3D fire and gas detector mapping, voting logic configuration, and coverage visualization for both building and industrial facilities, including indoor and outdoor environments. These assessments help verify detection effectiveness, eliminate blind spots, and ensure compliance with performance-based safety objectives.
Typical deliverables
- Design philosophies
- Permit drawings, zoning strategies, and early coordination with disciplines
- Review of the shop drawing
- System configurations, wiring diagrams, and wire schedules
- Riser diagrams for fire detection devices and notification appliances
- Cause and effect matrix
- Voltage‑drop and battery power supply calculations
- Complete drawings, specifications, and BOQs for tendering and construction
- 3D fire and gas detectors mapping
- AHJ liaison for smooth approvals and commissioning
- Field inspections and gap analysis with compliance reports
Our Scope Includes
Concept and permit layouts, zoning strategies, early coordination with disciplines
System configurations, wiring diagrams, and cable schedules
Field inspections and gap analysis with clear compliance reports
Shop drawing review
Voltage‑drop and battery/power supply calculations
Complete drawings, specifications, and BOQs for tender and construction
AHJ liaison for smooth approvals and commissioning
